Nickel foil-strip
| Standard | ASTM B162 |
| Materials | N02200, N02201,Ni200, Ni201, N2, N4, N6 |
| Length | As Your Required |
| Thickness | 0.01 mm - 0.5 mm |
| Width | 20-600mm |
| Tempers | Annealed, Full Hard, Deep Draw |
| Surface | No burr No oil spots |
| Packaging | Wooden cases |
We provide high quality Nickel Foil (Nickel Strip) with competitive prices and unrivaled customer service. We manufacture Nickel 200 and 201foil, strip, ribbon, sheets and plates, which conform to the ASTM B162 standard. Nickel Foil (Nickel Strip) commercially pure with good mechanical properties, and is resistant to a range of corrosive media.
ZircoSCM supplies a wide range of Nickel Foil (Nickel Strip) which are highly acclaimed by our clients due to its good luster, ductility, weldability, high conductivity and high quality.
Feature of Nickel Foil (Nickel Strip):
Ductility
Weldability
Anti-erosion resistance
High drawing tension
High degree of electrical conductivity
Low electrical resistivity
Excellent surface and slit edge conditions
Enhanced solderability as a result of low surface oxides
Excellent formability with deep draw characteristics with reduced die wear
Resistance to grain growth
Chemical requirements
|
Grade |
Ni+Co |
Cu |
Si |
Mn |
C |
Mg |
S |
P |
Fe |
|
N4 |
99.9 |
0.015 |
0.03 |
0.002 |
0.01 |
0.01 |
0.001 |
0.001 |
0.04 |
|
N6 |
99.6 |
0.10 |
0.10 |
0.05 |
0.10 |
0.10 |
0.005 |
0.002 |
0.10 |
|
Ni201 |
99.0 |
≤0.25 |
≤0.35 |
≤0.35 |
≤0.02 |
/ |
≤0.01 |
/ |
≤0.40 |
|
Ni200 |
99.0 |
0.20 |
0.30 |
0.30 |
0.15 |
/ |
0.01 |
/ |
0.40 |
Detection:
Visual inspection to check the quality of the surface, ensuring it without a flaw, black or any other defects.
Mechanical Features testing makes sure all nickel foils have satisfied mechanical features before delivery.
Chemical Composition Detection makes sure all chemical components can meet your demands.
ZircoSCM Nickel Foil Advantages:
Close Tolerances
Annealed to Full Hard
Precision Annealing & Cleaning
Special Finishes Available
Custom Packaging
R&D Prototype Orders
Large Production Runs
ZircoSCM has been an innovator in the production of light gauge nickel foil products. Each order is engineered according to your requirements and specifications with continual focus on products and process enhancement. We always bear in mind that your precision Nickel Foil (Nickel Strip) products require a sequence of repeatable rolling, slitting, annealing and finishing processes, tailored especially for your end use.
